Description
Dannmar 6,000-lbs. Capacity Rolling Bridge Jack – DJ-6000
Dannmar’s DJ-6000 Rolling Bridge Jack is the simple and safe way to turn your lift into a full-service car lift. With this Rolling Bridge Jack’s 6,000-lb. lifting capacity, you can take on even more types of vehicle repairs. Simply position the jack under the appropriate front or rear chassis area, and lift the vehicle up and off of the runways. Each chassis-engaging jack raises one-half of the vehicle, and two will raise all four wheels above the runways. Each four-post rolling bridge jack can be raised to three different heights. Locks engage automatically as the jack scissor arms raise, and they release simultaneously as the arms are lowered. Welded to the side of the rolling bridge jack, is a high-pressure, air-hydraulic pump that requires 125 psi and 10-20 CFM. It’s activated when you press a foot pedal attached to the unit.
Features
-
6,000-lb. lifting capacity
-
Rubber contact pads
-
Stackable adapters to maximize arm reach
-
High-pressure commercial air-hydraulic power unit; foot operated
-
Optional air-line kit
Specifications
| SKU | 5175326 |
|---|---|
| Lifting Capacity | 6,000 lbs. (2,722 kg) |
| Max. Height + Pad Only | 16.5” (419 mm) |
| Max. Height + Pad + Adapter | 20” (508 mm) |
| Min. Height + Pad Only | 6.5” (165 mm) |
| Min. Height + Pad + Adapter | 10” (254 mm) |
| Support Arm Width | 35” (889 mm) – 45.5” (1,156 mm) |
| Max. Arm Reach | 56” (1,422 mm) |
| Min. Arm Reach | 42” (1,067 mm) |
| Motor | Air-Hydraulic Pump |
| Noise | 45 dB |
| Lifting Time | 45 seconds |
